Eurolite - MOVING HEAD TMH BSW-380 Beam/Spot/Wash:

Extensive equipment

Also in terms of equipment, this all-around moving head has been designed with the utmost care. For example, 3 gobo wheels have been installed. The first gobo wheel offers 11 static gobos, the second 7 rotating gobos, and the third 4 static gobos and an area that enables animations. The latter creates movement in the projection, which alone, but also in combination with the other gobos, provides for eye-catching effects. For example, in combination with the textured glass rotating gobo and a prism, a sensational water effect can be generated. But also a kind of fire effect and many other moving images can be realized. The TMH BSW-380 has 2 rotating prisms. The first prism splits the image into 8 images, the second into 16. In addition, the moving head offers a motorized zoom that ranges from 4° to 35°.

Different modes

In beam mode, it achieves a hard, concentrated beam with a deliberate hotspot. For further shaping of the light beam, the static gobo wheel is available, for dynamics one can use the rotating prisms. As soon as the second or third gobo wheel is used, the spotlight automatically switches to spot mode. In this mode, the images are then absolutely even and clean, ideal for projections. All three gobo wheels can be combined here. The motorized focus ensures the necessary sharpness in all areas.

Beam/spot/wash moving-head with 371 W discharge lamp, color wheel, gobo wheels, prisms, frost, focus and zoom

Beam effect; spot effect; Wash effect
Light source: Osram Sirius HRI 371W discharge lamp
Lamp installed and adjusted ex factory
Additional frost filter provides a wide, soft and homogeneous light
Positioning within 540° PAN, 230° TILT
Auto position correction (feedback)
Exact 16 bit resolution at zoom, focus
Exact positioning (16 bit resolution)
Prism 16-fold; Prism 8-fold rotating; Prism 16-fold rotating; gobo wheel with static gobos; gobo wheel with rotating gobos; Focus motor-driven; Zoom motor-driven; frost filter; Dimmer
Color wheel with 13 dichroic filters plus open
Rainbow effect with adjustable speed in both directions
Gobo wheel with rotating gobos, 7 gobos and open
shake effect
Slot-in gobo system for easy gobo replacement
Gobos changeable
Gobo wheel with static gobos, 11 gobos and open
shake effect
Gobo wheel with static gobos, 5 gobos and open
shake effect
Integrated show programs
The device is cooled by cooling fan
Control via stand-alone; DMX; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
With a beam angle of 4° - 35°
Multicolor LCD display,
with battery buffering for easy controlling
Mains input and output for power linking up to 4 units
Color animations; patterns
Preprogrammed in Light Captain
For application areas such as: Clubs/dancing school; Stage; Rental
Application possibility: Standing; suspended

Package contents

1 x moving light, 1 x user manual, 1 x power cord, 2 x omega bracket

Power supply:

- 100-240 V AC, 50/60 Hz

Power consumption:

- 490 W

IP classification:

- IP20

Protection class:

- Protection class I

Power connection:

- Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)

Power output:

- P-Con (gray), mounting version

Fuse:

- 5 x 20 mm, T 8 A

Lamp type:

- Discharge lamp

Max. TILT movement:

- 230°

- Exact positioning (16 bit resolution)

- Auto position correction (feedback)

Max. PAN movement:

- 540°

- Exact positioning (16 bit resolution)

- Auto position correction (feedback)

Flash rate:

- 1 - 18 Hz

Equipment:

- Prism 16-fold

- Prism 8-fold rotating

- Prism 16-fold rotating

- Gobo wheel with static gobos

- Gobo wheel with rotating gobos

- Focus motor-driven

- Zoom motor-driven

- Frost filter

- Dimmer

Color generation:

- Color wheel with 13 dichroic filters plus open

- Rainbow effect with adjustable speed in both directions

Gobos:

- Gobo wheel with rotating gobos, 7 gobos and open

- Shake effect

- Outside diameter 22.5 mm

- Image diameter 12 mm

- Slot-in gobo system for easy gobo replacement

- Gobos changeable

- Gobo wheel with static gobos, 11 gobos and open

- Shake effect

- Gobo wheel with static gobos, 5 gobos and open

- Shake effect

DMX channels:

- 22; 26

DMX input:

- 3-pin XLR (M) mounting version

DMX output:

- 3-pin XLR (F) mounting version

Cooling:

- Cooling fan

Control:

- Stand-alone

- DMX

- Sound to light via Microphone

- Master/slave function

- QuickDMX via USB (optional)

- W-DMX by wireless solution via USB (optional)

- CRMX by LumenRadio via USB (optional)

Preprogrammed in:

- Light Captain

Beam angle:

- 4° - 35°

Beam angle (1/2 peak):

- Spot 4° - 35°

Beam angle (1/10 peak):

- Spot 4° - 35°

Housing color:

- Black

Display type:

- Multicolor LCD display with battery buffering

Use of brands:

- OSRAM bulb included

Dimensions:

- Width: 39.5 cm

- Depth: 30.5 cm

- Height: 63.0 cm

Weight:

- 22.70 kg

Noise classification:

- Class 3 (clearly perceptible sounds)

Legal specifications:

- Special product: Not designed for household room illumination

- Intended use: Show effect lighting

SKU: LUZ0952
